Van tự động Runxin 53510B (F75B1)

Technical Parameters:

    - Water Pressure-------0.15—0.6MPa

    - Water Temperature-----5℃-50℃

    - Transformer Output-----DC24V、1.5A

    - Water Turbidity----------＜20FTU

    - Inlet/Outlet-----------------2″M

    - Drain------------------------2″M

    - Base----------------------4″-8UN

    - Riser Pipe--------------1.5 ″D-GB

    - Max Flow Rate---------10 m3/h

    - Suitable Tank Size (in)---16″～24″

Product Characteristics：

    - It adopts hermetic head faces with high degree pottery and corrosion resistance for opening and closing.

    - No water passes the valve in rinse in single tank type.

    - LED dynamic screen display LED.The stripe on dynamic screen flash, it indicates the control valve is in service, otherwise, it is in rinse cycle.

    - Having long outage indicator

    - It could set up rinsing frequence

    - There are two kinds of time clock types: by hours or by days

    - Buttons are locked when no operation within 1 minute

    - Having interlock function

    - With signal output connector

    - With remote handling input connector

    - With pressure relief connector

    - All parameters can be modified according to the need

Range of Application:

    - Residential filtration system

    - Swimming pool filtration equipment

    - Active carbon or sand filter in RO pretreatment filtration system
